Harvester Engine

لا توجد مضمونات

Model	Cylinder bore x stroke(mm)	Displacement(L)	Rated power/speed(kW/rpm)	Max torque/speed(Nm/rpm)	Air intake	Application	Dimension(mm) and weight(kg)	Engine disposition
4DW91A50GG2	90×100	2.54	37/2400	164/1800~2000	Natural aspirated	Harvester	900×618×668 360kg	With PTO, without air filter, silencer and clutch
4DW91-45GG2	90×100	2.54	33/2400	150/1800~2000	Natural aspirated	Harvester	900×618×668 360kg	With PTO, without air filter, silencer and clutch
4DX21-63GG2	102X118	3.857	48/2400	245/1700~1900	Natural aspirated	Harvester	1005×661×795 380kg	With PTO, without air filter, silencer and clutch
CA4110/125TAG2	110X125	4.752	68/2400	315/1300-1500	Natural aspirated	Harvester	958×895×632 430kg	With silencer, without air filter and clutch
CA4110/125T	110X125	4.752	60/2200	305/1300-1500	Natural aspirated	Harvester	958×895×632 430kg	With silencer, without air filter and clutch
CA4DF2-11GG2	110X125	4.752	85/2300	410/1600-1800	Turbocharged	Harvester	1041×710×950 450kg	With PTO and silencer, without air filter and clutch
CA4DF2-12GG2			88/2300	450/1600-1800
CA4DF2-13GG2			96/2300	480/1600-1800
CA4DF2-14GG2			103/2300	500/1600-1800
CA6110/125ZT	110X125	7.127	103/2200	540/1300-1600	Turbocharged	Harvester	1310×721×1092 620kg	With silencer, without air filter and clutch
			118/2200	600/1300-1500	Turbocharged		1310×721×1092 620kg	With silencer, without air filter and clutch
			117/2200	600/1300-1500	Turbocharged		1310×721×1092 620kg	Without silencer, air filter and clutch
			118/2000	580/1300-1500	Turbocharged		1310×721×1092 620kg	With air filter and clutch
CA6110/125ZT-18GG2	110X125	7.127	132/2000	760/1300-1600	Turbocharged	Harvester	1310×721×1092 620kg	Without silencer, air filter and clutch
CA6DF1-16GG2	110X125	7.127	118/2200	680/1300-1700	Turbocharged	Harvester	1250×640×1050 700kg	Without silencer, with air filter
CA6DF1-16GAG2			118/2000	670/1300-1700	Turbocharged	Harvester	1250×640×1050 700kg	With silencer and air filter
CA6DF1-18GAG2			132/2200	770/1300-1700	Turbocharged	Harvester	1250×640×1050 700kg	Without silencer, with air filter
CA6DF1-18GG2			132/2000	770/1300-1700	Turbocharged		1250×640×1050 700kg	With silencer and air filter
CA6DF1-19GG2			140/2200	700/1300-1500	Turbocharged		1250×640×1050 700kg	Without silencer, with air filter
CA6DF1-20GG2			147/2000	810/1300-1700	Turbocharged		1250×640×1050 700kg	With silencer and air filter
CA6DF1-20GG2			147/2400	710/1300-1700	Turbocharged		1250×640×1050 700kg	With silencer
CA6DF1-22GG2			162/2200	830/1300-1700	Turbocharged and intercooled	Harvester	1250×640×1050 700kg	With silencer, without air filter
CA6DL2-22GAG2	112x145	8.7	162/2200	880/1500-1700	Turbocharged	Harvester	1280×700×1050 780kg	With silencer, without air filter
CA6DL2-24GG2			177/2200	960/1500-1700		Harvester
CA6DL2-26GG2			190/2200	1050/1500-1700		Harvester
